Pre-Configured Rack Cabinet - 27U (RB-AV27)

SKU RB-AV27

Manufacturer: Hammond Rack Basics

The RB-AV Series is a cost-effective rack cabinet that is ideal for A/V and Security applications. Fully assembled, the RB-AV Series includes pre-installed shelves, filler panels, casters, leveling feet and tapped 10-32 mounting rails.

$1,149.00 - $1,149.00

$1,149.00

$1,149.00 - $1,149.00

$1,149.00

Availability:

In stock

Quantity

Same Day Shipping
for most orders received before 2pm

FEATURES

Constructed in light duty 16-gauge steel.
Includes (5) x 2U Shelves and (5) x 2U filler/blank Panels pre-installed
Two (2) pairs of 19" EIA compliant tapped 10-32 mounting rails.
Starter pack of 10-32 screws and washers.
Locking tempered glass front door is opens a full 180°.
Locking solid steel rear door.
Doors can be flipped to hinge from opposite side.
Passive cooling vents located on top, bottom and sides.
Includes provision for up to two (2) optional fans on top panel.
Removable locking side panels.
Removable cable access panels on cabinet top and bottom.
Ships assembled - ready to install.
Bottom of cabinet includes four (4) adjustable leveling feet and four (4) recessed rubber casters that work great on carpet.
Shelf lip is folded down making it easy to slide equipment into the rack.
Rails can adjust in depth in 25mm increments.
Grounding studs provided on frame.
Finished in smooth black powder paint.
Tested to 950 lbs (431 kg) of equipment load capacity.
RoHS Compliant.
Dimensions: H 54.65" x W 23.62" x D 23.62"
