A1-16 Smart Servo (RC22ZZA001G)

A1-16 Smart Servo (RC22ZZA001G)

SKU RC22ZZA001G
Manufacturer: XYZ Printing
  • The A1-16 Smart Servo from XYZrobot provides temperature, speed, and position sensing functions.
$74.00 - $74.00
$74.00
$74.00 - $74.00
$74.00
Availability:
In stock

Same Day Shipping
for most orders received before 2pm

FEATURES

  • Operating Voltage: 12V
  • Stall Torque: 25 Kg-cm (max.)
  • No Load Speed: 70 +/- 10 rpm
  • Weight: 60 +/- 2 g
  • Size: 50 x 32 x 40 mm(1.97 x 1.26 x 1.57 in.)
  • Resolution: 0.323°
  • Reduction Ratio: 254
  • Operating Angle: 0° ~ 330°
  • Operating Current: 500mA
  • Standby Current: 30mA max.
  • Operating Temperature: 0°C to 40°C (32°F to 104°F)
  • Protocol: TTL Level UART (8-N-1)
  • Feedback: Position, Temperature, Current, Supply Voltage

ACCESSORIES

REPLACEMENTS

  • Operating Voltage: 12V
  • Stall Torque: 25 Kg-cm (max.)
  • No Load Speed: 70 +/- 10 rpm
  • Weight: 60 +/- 2 g
  • Size: 50 x 32 x 40 mm(1.97 x 1.26 x 1.57 in.)
  • Resolution: 0.323°
  • Reduction Ratio: 254
  • Operating Angle: 0° ~ 330°
  • Operating Current: 500mA
  • Standby Current: 30mA max.
  • Operating Temperature: 0°C to 40°C (32°F to 104°F)
  • Protocol: TTL Level UART (8-N-1)
  • Feedback: Position, Temperature, Current, Supply Voltage

❮ ❯

❮ ❯
